Description
The Savaria V-1504 VPL (vertical platform lift) is built to carry a wheelchair and passenger safely up and down one or more levels. Suitable for installations in public and commercial buildings, as well as private homes, this Savaria lift features an extremely versatile design that can be configured and customized to suit virtually any project requirements and aesthetic needs. From the rugged outdoors, to the most luxurious office tower lobbies, the Savaria V-1504 lift is ready to serve with its reliable performance, ease of use and range of finish options.
Flexible enclosure design: Can be built to suit virtually any home or commercial project. Enclosed with aluminum and acrylic inserts and top dome with active ventilation system; corrosion-resistant steel components, make it ideal for outdoor applications.
Quiet and reliable hydraulic drive: Smooth start, stop and overall ride that works dependably.
Machine roomless: Enclosed drive system means no machine room is required, making the installation process easier.
Other standard features: 36″ x 54″ standard platform, continuous pressure button operation, modular rail construction for easy construction, handrail.
Standard finish: Beige powder-coat paint.
Safety features: Emergency stop button on car, non-skid platform, manual lowering device, 42 1/8″ (1070 mm) side panels, keyed car buttons and keyed call stations, safety brake, door locks.
Specifications
Applications: Residential, commercial, indoors, outdoors
Standard capacity: 750 lb (340 kg)
Maximum travel distance: 23′ (7 m), subject to local code; commercial use in the USA limited to 12′ to 14′ (3.65 to 4.26 m) depending on the year of code enforced
Nominal speed: 20 ft/min (0.1 m/s)
Drive/motor: 2:1 chain hydraulic, 3 hp (2.2 kW), gear-type motor
Minimum pit: 3″ (76.2 mm)
Power supply: 120 VAC, 20 amp, single phase, 60 Hz
Optional configurations: Type 1, 2, 3 and 4
Platform sizes:
W36″ x L48″ (914 mm x 1219 mm), Type 1, 2, 3, 4
W36″ x L54″ (914 mm x 1371 mm), Type 1, 2, 3, 4
W36″ x L60″ (914mm x 1524 mm), Type 1, 2, 3, 4
Custom sizes up to 42″ x 60″ (1067 mm x 1524 mm)
Enclosure options: Can be ordered with tempered or laminated glass panels, or acrylic panels. Gates and door can be motorized.
Optional finishes: A wide array of powder-coat colors in gloss, semi gloss or textured finish are available, including custom color (see color chart).
Other options: Up to 4 stops, commercial package including alarm, keyless operation, keyed or keyless hall call (subject to type of application), low profile aluminum doors, ProDoor (ULC fire-rated) for 3-sided applications, power gate and door operators, tempered glass inserts for doors, acrylic inserts for gate, GAL or Savaria WR-500 weather resistant lock, folding seat, 60 mm buttons, ADA hands-free phone, battery backup.
Warranty
We offer a 36-month manufacturer’s parts warranty on all Savaria wheelchair lifts.
Term of warranty – this warranty is valid for a period of 36 months* from the date that the product shipped from our factory. Purchase price for product must be paid in full for manufacturer to release parts under this warranty.
Coverage – this warranty applies to the repair or replacement, at Manufacturer’s option, of parts that fail due to defective material or workmanship. Manufacturer may, at its option, provide factory reconditioned parts. This warranty is provided to the Authorized Savaria Dealer on behalf of the final purchaser of the product and is not transferable. The Manufacturer’s warranty does not cover labor charges for the removal, repair or replacement of warranty parts but such costs may be covered for a period of time by Authorized Dealer’s warranty, which is provided to purchaser separately.
Conditions:
1. This warranty only applies to products installed and maintained by an Authorized Savaria Dealer in conformance with all applicable local and national codes.
2. The warranty is void if regular inspection and maintenance of product is not being carried out by an Authorized Savaria Dealer in accordance with the recommendations contained in the Owner’s Manual. It is the Owner’s responsibility to keep records of all such service. To maintain warranty, products installed in harsh environments (e.g. salt water, temperature extremes), will require additional maintenance.
3. This warranty does not apply to the following:
- Consumable items which include: light bulbs, batteries, UPS (uninterruptible power supplies), oil seals, mechanical switches, guide shoe inserts, drive belts, hydraulic fluids, greases, oils, etc.
- Structural or cosmetic components that are subject to normal wear and tear, external forces and/or misuse. This includes metal panels, glass, acrylic, gates, travelling cable, doors, buttons, switches, upholstery, trim, etc.
- Items that require periodic assessment, maintenance and/or replacement. This includes paint, caulking, weather seals, etc.
- Malfunction or damage to product caused by accident, misuse, abuse or vandalism, lack of proper maintenance, improper installation or placement of product, neglect, improper adjustment, modification or alteration, structural condition of building or hoist way, overloading, failure to follow operating instructions or acts of God.
Standard Procedures:
Required warranty parts will be shipped at Savaria’s expense by FedEx ground. Expedited or air shipment of parts is available at Dealer’s request and expense. Some parts covered under this warranty may be commercially available from a source close to the job site and Savaria will reimburse Dealer for cost to purchase these items provided that approval is obtained from Savaria’s Technical Support Department in advance.
Disclaimers:
Savaria (Savaria Concord Lifts, Inc.) disclaims liability for any personal injury or property damage resulting from the operation of a product that has been modified from the original Savaria design. No person or company is authorized to change the design of this product without written authorization by Savaria.
Savaria’s obligation under this warranty is exclusively limited to the repair or exchange of parts that fail within the applicable warranty period.
Savaria assumes no responsibility for expenses or damages, including incidental or consequential damages. Some states and/or provinces do not allow the exclusion or limitation of incidental or consequential damages so the above limitation may not apply to you.
This Warranty supersedes all other published warranties in Owner’s and Installation Manuals and applies to sales after November 14, 2005. *For the Savaria S64, C65 and Roby, the warranty period is limited to 24 months. For Quebec projects with the S.H.Q / P.A.D program , S.A.A.Q and C.S.S.T , the warranty terms shall be the same limited warranty but for a period of 12 months.
